Product Overview
Product Features
Features of MEISHO MS9000SE BGA Repair Station:
Higher repair efficiency and success rate can greatly reduce repair costs;
Four-point automatic alignment technology allows anyone to operate correctly;
Completely ensures quality issues are addressed;
Depending on the component assembly method, even without considering the repair or installation of chip components, there is no need to purchase new equipment if necessary, as long as the required parts are available.
Product Specifications
| System Specifications | MS9000SE TP | MS9000SE PC | MS9000SE (TP/PC) LL |
| Maximum Substrate Size Parentheses indicate the maximum installable substrate size | 300×400mm (300×400mm) | 300×400mm (300×400mm) | 400×500mm (460×600mm) |
| Target Component Size | □1~□50 (0402～Option) | □1~□50 (0402～Option) | □1~□50 (0402～Option) |
| Power Requirements | Single-phase AC 200V~240V approx. 2.5KVA (12.5A) | Single-phase AC 200V~240V approx. 2.5KVA (12.5A) | Single-phase AC 200V~240V approx. 4.5KVA (22.5A) |
| Top Heater | 1040W | 1040W | 1040W |
| Standard Bottom Heater | 1000W | 1000W | 1000W |
| Wide Bottom Heater | One | One | 2000W |
| Control Method | PLC | PLC | PLC |
| Operation Unit (Display Method) | Touch Screen Optical Unit Output LCD | Windows PC LCD | Touch Screen / Optical Unit Output LCD Windows PC LCD |
| Connected Thermometers | K-type Thermocouple 1~6 channels | K-type Thermocouple 1~6 channels | K-type Thermocouple 1~6 channels |
| Temperature Curve Acquisition Mode | Automatic Mode Manual Mode | Automatic Mode Manual Mode | Automatic Mode Manual Mode |
| System Dimensions | 1300(W)×700(D)×950(H)mm | 1050(W)×700(D)×950(H)mm | 1450(W)×850(D)×950(H)mm |
